Our Internal Gear Capabilities
Depth of Cut: 6 inch maximum
Diameter: Max 24” CNC (Max 36” Traditional cut)
Pitch: Min 48 DP Max 3 DP
.5 Mod 8.5 Mod
Internal/Shaper Cut Gears
Internal gears are often overlooked for the importance they play in the gear industry. Most machine manufacturers cater to making traditional gear cutting machines versatile, while ‘shapers’ that cut internals, remain defined by a narrow band of characteristics. That said, we can say that over the years we have literally cut many thousands of parts in our Fellows Type 7 and 36 gear shapers, taking them to the limits of their specifications or even modifying the machine, to create the gear needed by our customer.
The integral key part of internal gears is their fit to the mating part. We specialize in providing gears that have exact tolerances that demand either an interference or clearance fit with mate. Our sales and engineering team will work with you to decide which mating fit you require.
With the acquisition of our new CNC shaper, we can continue to produce gears with higher accuracies and ensure the exact fit required with the mating part.
Well-designed internal gears play a critical role in optimizing power and motion transmission in various mechanical devices and systems. At Circle Gear & Machine Co., our customized manufacturing approach allows us to fine-tune each internal gear solution to the client’s exact technical specifications. We also offer heat treatments and finishing services to further optimize the gear for its end use.
Our operational flexibility allows us to process large and small production volumes quickly and affordably. Regardless of the project size or complexity, we have the skills, experience, and equipment to ensure precision-cut internal gears that will keep your operations running smoothly and efficiently.
To learn more about our internal gears and gear-cutting services, please request a quote.
Custom Internal Gears Capabilities
|General Capabilities||As Needed|
|Primary Capabilities||Die Forming|
|Gray Cast Iron
Heating, Ventilation, and Air Conditioning
Oil, Gas, Petroleum
Pulp & Paper
|Gear Cutting Method||Broaching|
|Gear Forming Method||Centrifugal Casting
|Heat Treatment Methods||Carburizing|
|Production Volume||Specialty Production Shop|
Large Scale Production Volume Run
